Characteristics:

• Two-stage decelerating stucture is adopted for the drive axle.
• The wheel is planetary decelerating structure.
• The main reducer is equipped with the common bevel-gear differential mechanism with simple structure and flexible differential function.
• Cast steel with adequate rigidity serves as material for the axle housing.
• The brake in enclosed multi-disc wte-type braking mode,with baking semi shft,hydraulic pressing,spring release and excellent braking performance is installed in front of the planetary hub decelerating-gears.
