Characteristics:

• Two-stage decelerating mechanism is adopted for the drive axle.
• The spiral bevel gears with great load carrying capacity and high efficiency are adopted for main drive.
• The hub is planetary decelerating structure.
• The main reducer is equipped with the common bevel-gear differential with simple structure and flexible differential function.
• Cast steel with adequate rigidity serves as the material for the axle housing.
• The drive axles with either of the two turning directions are provided in accordance with suers’ requirements.
• The brake in clamp-disc braking mode has great braking moment.
